Is gnách le Maighnéad sorcóir trí seafta MGP (Sorcóir Treorach Rod), agus is féidir leis dhá imthacaí, cineál imthacaí sleamhnáin nó cineál imthacaí liathróid a thairiscint.
Tá an tolladh ó 12mm go 100mm, agus an stróc ó 0 go 200mm.
Is é ár meaisín CNC féin a tháirgeann an t-ábhar coirp, agus allmhairítear na rónta tábhachtacha ón tSeapáin, Taiwan, chun an leibhéal ardcháilíochta a chinntiú.
Is é ardfheidhmíocht, cuma álainn, sorcóir MGPM ó JXPC an rogha is fearr duit!
Bore (mm) | 12 | 16 | 20 | 25 | 32 | 40 | 50 | 63 | 80 | 100 |
Brú oibre (Barra) | 1.2-10.2 | |||||||||
Teocht oibre | -10-60 | |||||||||
Luas loine (mm / s) | 50-500 | 50-400 | ||||||||
Cushion | Ruvvwe cuahion | |||||||||
Bore (mm) | 12 | 16 | 20 | 25 | 32 | 40 | 50 | 63 | 80 | 100 | |
Lamháltas stróc | 1.5 | ||||||||||
Ag iompar | Imthacaí sleamhnáin / Imreoir liathróid | ||||||||||
Cruinneas neamh-ródúcháin | Imthacaí sleamhnáin | ±0.08° | ±0.07° | ±0.06° | ±0.05° | ±0.04° | |||||
Treoir liathróid | ±0.10° | ±0.09° | ±0.08° | ±0.06° | ±0.05° | ||||||
Méid an Chalafoirt | M5×0.8 | G1/8 | G1/4 | G3/8 | |||||||
Méid Bore | B | C | FA | FB | FC | FD | FE | FF | FG | FH | G | H |
12 | 42 | 29 | 7 | 6 | 80 | 89 | 18 | 25 | 4.5 | 5 | 26 | 58 |
16 | 46 | 33 | 7 | 6 | 88 | 98 | 22 | 32 | 5.5 | 5 | 30 | 64 |
20 | 53 | 37 | 8 | 8 | 102 | 112 | 24 | 38 | 5.5 | 6 | 36 | 83 |
25 | 53.5 | 37.5 | 9 | 7 | 114 | 126 | 30 | 40 | 6.6 | 6 | 42 | 93 |
32 | 59.5 | 37.5 | 10 | 12 | 138 | 154 | 34 | 50 | 9 | 9 | 48 | 112 |
40 | 66 | 44 | 10 | 12 | 146 | 162 | 40 | 60 | 9 | 9 | 54 | 120 |
50 | 72 | 44 | 10 | 12 | 178 | 198 | 46 | 65 | 11 | 10 | 64 | 148 |
63 | 77 | 49 | 12 | 16 | 192 | 212 | 58 | 75 | 11 | 10 | 78 | 162 |
80 | 96.5 | 56.5 | 16 | 24 | 238 | 262 | 54 | 90 | 13.5 | 16 | 91.5 | 202 |
100 | 116 | 66 | 19 | 31 | 280 | 308 | 62 | 100 | 15.5 | 22 | 111.5 | 240 |
